ENGINE

• Model 2014
• Serial 1P39QMB 4STROKE
• Bore×Stroke   (mm) 39×41.5
• Displacement  (ml) 49.6
• Compress Rate 10.4:1
• Max Power  (kW/r/min) 2.4/7000±500
• Rated Power  (kW/r/min) 2.1/6500±500
• Max Torque  (N·m/r/min) 3.6/6000±500
• Idle Speed  (r/min) 1700±100
• Fuel Consumption  (g/kW·h) 400
• Start Electric / Kick
• Ignition C.D.I
• Transmission V-Belt
• Fuel Tank  (L) 4.90

DIMENSION

• L×W×H  (mm) 1780×640×1120
• Wheel Base (mm) 1250
• Ground Clearance(mm) 110
• Seat Light  (mm) 750
• N.W  ( LBS) 190
• G.W. (LBS) 200

Driven System

• Rim(F/R) 2.15×12  /  2.15×12 Alloy Rim
• Tire(F/R) 120/70-12   /  120/70-12  Huajian
• Brake Type F Hydraulic Disc / R Drum
• Operation Type F/R  Hand Operation

Electric System

• Spark Plug Type / Gap(mm) A7RTC  /  0.6?0.7
• Battery Type 12V 5Ah
• Head Light Double Light(LED)

Main Performance

• Max Speed (km/h) 52
• Start Time(s)    15
• Rconomic Fuel Consumption(L/100km) 2.0
