FRAMESET
Frameset: 6061 Aluminum Alloy
Fork: Hydraulic Front Fork, T: 100mm
WHEELS & BRAKING
Tires: KENDA 27.5 x 2.4"
Brakes: Tektro Hydraulic Disc Brakes
Rotor: 180 x 1.9 mm
MOTOR & DRIVETRAIN
Motor: 750W Hub Motor (Galaxy eDrive System)
Torque: 75 Nm
Drivetrain: Shimano Altus 8-Speed (12-32T)
Chainring: 48T
Pedal Assist: Dual Sensor (Torque + Cadence)
BATTERY & PERFORMANCE
Battery: 864Wh
Certification: UL 2849 (Whole Bike), UL 2271 (Battery)
Charger: 54.6V / 3A
Max Speed: 28 MPH
Max Range: Up to 100 Miles (Tested with a 155 lb rider using PAS1)
DISPLAY & CONNECTIVITY
Display: LCD Color Display
App: Heybike Smart App (iOS & Android)
LIGHTING & UTILITY
Front Light: White Light with Horn
Rear Light: Taillight with Brake & Turn Signals
Rack Capacity: 66 lb
Payload Capacity: 440 lb
Fenders & Rear Rack: Included
WEIGHT & DIMENSIONS
Bike Weight: 69 lb
Dimension: 75.8 x 27.6 x 42.1 - 44.9"
