FRAMESET
Frame: 6061 Aluminum Alloy
Fork: Aluminum rigid Fork
WHEELS & BRAKING
Tires: KENDA 27.5x2.2"
Brakes: Hydraulic Disc Brakes
Rotor: 180 x 1.9 mm
MOTOR & DRIVETRAIN
Motor: 750W Hub Motor (Galaxy eDrive System)
TorqueL 70 Nm
Drivetrain: Shimano Altus 8-Speed (11-32T)
Chainring: 48T
Pedal Assist: Up to 85 Miles (tested with a 155 lb rider in PAS1, no throttle applied)
BATTERY & PERFORMANCE
Battery: 680Wh
Certification: UL 2849 (Whole Bike), UL 2271 (Battery(
Charger: 54.6V / 2A
Maz Speed: 28 MPH
Max Range: Up to 85 Miles (tested with a 155 lb rider in PAS1, no throttle applied)
DISPLAY & CONNECTIVITY
Display: LCD Color Display
App: Heybike Smart App (iOS & Android)
LIGHTING & UTILITY
Front Light: White Light with horn
Rear Light: Integrated Turn Signal, Rear Red LED (optional)
Rack Capacity: 66 lb
Fenders & Rear Rack: Optional
WEIGHT & DIMENSIONS
Bike Weight: 50 lb
Dimensions: 72.8" x 29.5" x 40.9" / 43.7"
Metric: 1850x750x1040/1100 mm
